With their high-efficiency cooling systems, plate ice machines produce large volumes of ice in a short time. The thin, flexible ice sheets are perfect for applications requiring quick cooling or large surface area, such as in industrial cooling and food preservation.
Plate ice machines are compact yet highly efficient, making them a great option for businesses with limited space but high ice demand. These machines freeze water on large aluminum plates to form continuous sheets of ice, which can then be broken into smaller pieces for use in cooling and refrigeration applications. The thin, flexible ice is perfect for cooling products quickly and effectively, with minimal wastage.
Despite their compact size, plate ice machines are capable of producing large quantities of ice in a short period. They are equipped with advanced refrigeration technology to ensure consistent ice production and high energy efficiency. Ideal for restaurants, supermarkets, and smaller food processors, these machines are designed to fit into tight spaces without compromising on performance.
| Subject | Unit | Technical parameter | |
| Power supply | Voltage/Phase/Frequency | 220V~480V/3P/50~60Hz | |
| Refrigerant | / | R22/R404A/R507A/R448A/R449A/R717 | |
| Capacity | Kg/day | 10000 | |
| Cooling way | Water Cooling | ||
| Temperature | Ambient temperature | ℃ | 35 |
| Water inlet temperature | ℃ | 20 | |
| Operating power | Cooling water pump | Kw | 1.1 |
| Warm water pump | Kw | 0.75 | |
| lce cutter | Kw | 1.1 | |
| Cooling tower fan | Kw | 1.1 | |
| Cooling water pump | Kw | 2.2 | |
| Total running power | Kw | 39.07 | |
| Installment power | Kw | 48 | |
| Compressor | Manufacturer | Bitzer | |
| Refrigeration capacity | Kw | 71 | |
| Operating power | Kw | 32.82 | |
| Compressor COP/EER | Kw/Kw | 2.16 | |
| Horse power | Hp | 25x2sets | |
| Type of compressor | Semi-hermetic screw | ||
| Dimension | Size of machine unit | L×W×H(mm) | 1600x1200x1800 |
| Number of evaporator | 1PC | ||
| Size of evaporator | L×W×H(mm) | 2200x1700x2200 | |
| Size of ice outlet | L×W(mm) | 1500x300 | |
| Size of cooling tower | O.D.×H(mm) | C2000x2410 | |
| Size of water feeding pipe of cooling tower | 3/4" | ||
| Size of cooling water pipes | 2-1/2" | ||
| Size of water feeding pipe | 3/4" | ||
| Operating weight | Unit | Kg | 1150 |
| Evaporator | Kg | 1460 | |
| Cooling tower | Kg | 670 | |
| Water supply pressure requirement | Bar | 1 | |
