Cube ice machines efficiently produce uniform, high-quality ice cubes ideal for commercial and industrial use. Using advanced refrigeration technology, they ensure consistent ice production, low maintenance, and reliable performance for bars, restaurants, and supermarkets.
Cube ice machines are designed to produce uniform, solid cubes of ice quickly and efficiently. Using advanced refrigeration technology, these machines freeze water into crystal-clear cubes, which are ideal for use in bars, restaurants, hotels, and supermarkets. With their reliable performance and consistent ice production, cube ice machines ensure a steady supply of ice for daily operations.
Easy to install and operate, these machines come in a variety of sizes, making them suitable for small businesses and large-scale operations alike. With features such as automatic water filling, ice harvesting, and self-cleaning, cube ice machines are designed to provide hassle-free ice production with minimal maintenance.
Key Features:
| Subject | Unit | Technical parameter | |
| Power supply | Voltage/Phase/Frequency | 220V~480V/3P/50~60Hz | |
| Refrigerant | / | R22/R404A/R507A/R448A/R449A/R717 | |
| Capacity | Kg/day | 15000 | |
| Temperature | Ambient temperature | ℃ | 35 |
| Water inlet temperature | ℃ | 20 | |
| Operating power | Total running power | Kw | 48.4 |
| Installment power | Kw | 60 | |
| Operating power of cutter | Kw | 1.1 | |
| Operating power of cold water pump | Kw | 1.5 | |
| Fan motor of cooling tower | Kw | 1.5 | |
| Operating power of cold water pump | Kw | 3.7 | |
| Manufacturer | Bitzer | ||
| Refrigeration capacity | Kw | 109.4 | |
| Operating power | Kw | 40.6 | |
| Compressor | Compressor COP/EER | Kw/kw | 2.7 |
| Horse power | Hp | 35×2 | |
| Cooling way | Water cooling | ||
| Dimension | Size of ice maker | (LxWxH)(mm) | Unit:2000x1800x1600 Evaporator:1250x1250x4200 |
| Size of cooling tower | (O.D.xH)(mm) | Φ2175x2565 | |
| Size of liquid pipe of cooling tower | 3/4" | ||
| Size of cooling water pipe | 2-1/2" | ||
| Size of water inlet pipe of ice maker | 1" | ||
| Size of ice outlet | mm | 400x300 | |
| Weight of unit | Operating weight of cube ice maker | Kg | Unit:1890 Evaporator:2685 |
| Operating weight of cooling tower | Kg | 1120 | |
| Water supply pressure requirement | Bar | 1.5 | |
