Plate ice machines are designed to produce thin, flat sheets of ice that are ideal for cooling, preserving food, and industrial applications. These machines use a direct refrigeration process to freeze water into ice plates, providing fast and efficient cooling with minimal energy consumption.
Plate ice machines are designed to produce high-quality, uniform ice sheets by freezing water over large evaporator plates. These machines are ideal for use in seafood preservation, food processing, and cooling systems, providing clean and solid ice that is easy to handle and store. The thin, flexible ice produced by plate ice machines is perfect for maintaining the freshness of perishable goods, as it evenly surrounds and cools them.
With automated features such as water filling, ice production, and harvesting, plate ice machines offer convenience and efficiency. Their robust design ensures consistent ice production, and they are built to withstand heavy-duty use in industrial environments. Whether for commercial or industrial applications, plate ice machines are reliable, low-maintenance, and energy-efficient, making them an essential piece of equipment for businesses requiring large volumes of ice.
Key Advantages：
| Subject | Unit | Technical parameter | |
| Power supply | Voltage/Phase/Frequency | 220V~480V/3P/50~60Hz | |
| Refrigerant | / | R22/R404A/R507A/R448A/R449A/R717 | |
| Capacity | Kg/day | 24000 | |
| Cooling way | Water Cooling | ||
| Temperature | Ambient temperature | ℃ | 35 |
| Water inlet temperature | ℃ | 20 | |
| Operating power | Cooling water pump | Kw | 3 |
| Warm water pump | Kw | 1.1 | |
| lce cutter | Kw | 2.5 | |
| Cooling tower fan | Kw | 2.5 | |
| Cooling water pump | Kw | 5.5 | |
| Total running power | Kw | 100.1 | |
| Installment power | Kw | 125 | |
| Compressor | Manufacturer | Bitzer | |
| Refrigeration capacity | Kw | 177.2 | |
| Operating power | Kw | 85.8 | |
| Compressor COP/EER | Kw/Kw | 2.07 | |
| Horse power | Hp | 70x2sets | |
| Type of compressor | Semi-hermetic screw | ||
| Dimension | Size of machine unit | L×W×H(mm) | 2700x2200x2200 |
| Number of evaporator | 1PC | ||
| Size of evaporator | L×W×H(mm) | 4500x2200x2450 | |
| Size of ice outlet | L×W(mm) | 1500x300 | |
| Size of cooling tower | O.D.×H(mm) | Φ2650×2565 | |
| Size of water feeding pipe of cooling tower | 1" | ||
| Size of cooling water pipes | 4" | ||
| Size of water feeding pipe | 1" | ||
| Operating weight | Unit | Kg | 2450 |
| Evaporator | Kg | 3250 | |
| Cooling tower | Kg | 1300 | |
| Water supply pressure requirement | Bar | 1 | |
